CARTERS PARA KYMCO GRAND DINK 125 4T EURO II

CARTERS para Kymco GRAND DINK 125 4T EURO II
(1)
(1)  11100-KKC1-305
CRANK CASE RIGHT
(2)
(2)  11102-1G87-004
RUBBER BUSH ENGINE HANGER
(3)
(3)  11192-LEA5-E00
GASKET CRANK CASE
(4)
(4)  11200-KKC3-315
CRANK CASE LEFT
(5)
(5)  11203-GGC7-W10
UNDER RUBBER BUSH REAR CUSHION
(6)
(6)  11341-KKC3-900-N8A
COVER LEFT SIDE (LIGHT SILVER METAL)
(7)
(7)  11383-KUDU-C00
CLAMPER BREATHER DRAIN TUBE
(8)
(8)  11395-LEA5-E00
GASKET LEFT COVER
(9)
(9)  1541A-KKC3-900
ELEMENT ASSY OIL FILTER
(9*)
(9*)  1541A-KKC3-900
ELEMENT ASSY OIL FILTER
(10)
(10)  15421-KKC3-900
CAP OIL FILTER
(11)
(11)  15422-KKC3-900
O-RING 58 X 54 X 2,6
(12)
(12)  15423-KKC3-900
SPRING OIL FILTER SCREEN
(13)
(13)  28223-KNBN-W10
SPRING KICK DRIVEN GEAR
(14)
(14)  28230-KNBN-901
GEAR COMP KICK DRIVEN
(15)
(15)  28250-KFC8-900
SPINDLE COMP KICK STARTER
(16)
(16)  28253-GBN2-C00
BUSH KICK SPINDLE
(17)
(17)  28255-GFS6-C00
WASHER (5.11X33.48X36.98)
(18)
(18)  28281-KKC2-900
SPRING KICK RETURN
(19)
(19)  50504-KKC3-900
STOPPER RUBBER MAIN STAND
(20)
(20)  90031-KEBE-900
BOLT STUD M08
(21)
(21)  90032-KHD6-900
BOLT STUD M08X210
(22)
(22)  90412-3K29-C00
WASHER THRUST (1.00X10.00X18.00)
(23)
(23)  90451-GBN2-C00
WASHER PLAIN (2.06X14.20X20.96)
(24)
(24)  9052A-PUA3-B50
BOLT ASSY DRAIN PLUG 12*15
(25)
(25)  96100-62040-00
BEARING BALL (6204) 20X47X14
(26)
(26)  91202-KKJ9-C00
OIL SEAL 20 X 32 X 6-AS
(27)
(27)  91261-4E15-004
OIL SEAL 25 X 40 X 8 - A
(28)
(28)  94301-08140
PIN DOWEL 8X14
(29)
(29)  94511-14000
CIRCLIP EX D14
(30)
(30)  95801-08012-08
BOLT FLANGE (M08X12) (GOLD)
(31)
(31)  96001-06016-06
BOLT FLANGE (M06X16) (BLACK)
(32)
(32)  95701-06022-08
BOLT FLANGE (M06X22) (GOLD)
(33)
(33)  96001-06050-08
BOLT FLANGE (M06X50) (GOLD)
(34)
(34)  96001-06060-06
BOLT FLANGE (M06X60) (BLACK)
(35)
(35)  96001-06120-08
BOLT FLANGE (M06X120) (GOLD)
(36)
(36)  96100-62030-00
BEARING BALL (6203) 17X40X12
No peça Descrição
# 1
11100-KKC1-305
CRANK CASE RIGHT
# 2
11102-1G87-004
RUBBER BUSH ENGINE HANGER
# 3
11192-LEA5-E00
GASKET CRANK CASE
# 4
11200-KKC3-315
CRANK CASE LEFT
# 5
11203-GGC7-W10
UNDER RUBBER BUSH REAR CUSHION
# 6
11341-KKC3-900-N8A
COVER LEFT SIDE (LIGHT SILVER METAL)
# 7
11383-KUDU-C00
CLAMPER BREATHER DRAIN TUBE
# 8
11395-LEA5-E00
GASKET LEFT COVER
# 9
1541A-KKC3-900
ELEMENT ASSY OIL FILTER
# 9*
1541A-KKC3-900
ELEMENT ASSY OIL FILTER
# 10
15421-KKC3-900
CAP OIL FILTER
# 11
15422-KKC3-900
O-RING 58 X 54 X 2, 6
# 12
15423-KKC3-900
SPRING OIL FILTER SCREEN
# 13
28223-KNBN-W10
SPRING KICK DRIVEN GEAR
# 14
28230-KNBN-901
GEAR COMP KICK DRIVEN
# 15
28250-KFC8-900
SPINDLE COMP KICK STARTER
# 16
28253-GBN2-C00
BUSH KICK SPINDLE
# 17
28255-GFS6-C00
WASHER (5.11X33.48X36.98)
# 18
28281-KKC2-900
SPRING KICK RETURN
# 19
50504-KKC3-900
STOPPER RUBBER MAIN STAND
# 20
90031-KEBE-900
BOLT STUD M08
# 21
90032-KHD6-900
BOLT STUD M08X210
# 22
90412-3K29-C00
WASHER THRUST (1.00X10.00X18.00)
# 23
90451-GBN2-C00
WASHER PLAIN (2.06X14.20X20.96)
# 24
9052A-PUA3-B50
BOLT ASSY DRAIN PLUG 12*15
# 25
96100-62040-00
BEARING BALL (6204) 20X47X14
# 26
91202-KKJ9-C00
OIL SEAL 20 X 32 X 6-AS
# 27
91261-4E15-004
OIL SEAL 25 X 40 X 8 - A
# 28
94301-08140
PIN DOWEL 8X14
# 29
94511-14000
CIRCLIP EX D14
# 30
95801-08012-08
BOLT FLANGE (M08X12) (GOLD)
# 31
96001-06016-06
BOLT FLANGE (M06X16) (BLACK)
# 32
95701-06022-08
BOLT FLANGE (M06X22) (GOLD)
# 33
96001-06050-08
BOLT FLANGE (M06X50) (GOLD)
# 34
96001-06060-06
BOLT FLANGE (M06X60) (BLACK)
# 35
96001-06120-08
BOLT FLANGE (M06X120) (GOLD)
# 36
96100-62030-00
BEARING BALL (6203) 17X40X12
Aqui estão todas as peças relacionadas com a CARTERS de seu GRAND DINK 125 4T EURO II de DINK. Estas são peças todas genuínas para assegurá-lo o melhor reparo possível que vai durar.
